The electric pinch valve uses a motor to drive the spool movement, thereby squeezing or loosening the hose between the spool and the stop strip to control the flow of fluid in the hose. The fluid medium is only passed through the hose to avoid contact with other parts of the valve body resulting in contamination. Compared with the traditional electromagnetic pinch valve, the electric pinch valve has better energy saving effect, lower electromagnetic interference and stronger pressure resistance.lg...

Engineered for Tough Slurries Manual Operated Pinch Valves are reliable, maintenance-free, cost-effective valves engineered for tough slurries, abrasives, and corrosive chemical applications. The 100% full port design eliminates any dead spots or crevices, seats or bearings where slurry can hang up and impair operation or even cause complete valve failure. Manual Pinch Valves employ high quality elastomer technology to provide smooth venturi flow, centerline closure, and excellent throttling characteristics. lg...

Air Actuated Pinch Valves offer a cost-effective solution to flow control problems. The secret is in the rubber sleeve - the valve's only wetted part. Actuation of the valve is accomplished by air or hydraulic pressure placed directly on the elastomer sleeve. The valve body acts as a built-in actuator, eliminating costly hydraulic, pneumatic, or electric operators. The sleeve's rugged flexibility allows the valve to close drop tight around entrapped solids. In general, 25 psi over line pressure is required for full closure of air actuated pinch valves. lg...

MGJ41X-10Q Series Rubber Seated Pinch ValveDesign and Manufacturing: ASME B16.34, Factory StandardFlange Ends: DIN 2544, ASME B16.5, RF Flange Connection (can be according to customer's request.)Face to Face dimension can be customized. Body: Aluminum alloy, Cast Iron, Ductile IronBranch Pipe Material: Natural Rubber, NBR Composition, EPDM, High Performance Wear-resistant Modified Rubber. Temperature Range: -30℃ to 120℃lg...

Technical Specification ● Design and Manufacture: Factory Standard ● Face to face: Factory Standard ● End Flange: DIN 2544, ASME B16.5 (or drilling according to customer’s requirements) ● Inspection and Test: API 598 ● Size range: DN40 to DN300 ● Body Material: Aluminum, Carbon Steel ● Sleeve Material: Natural Rubber, EPDM, Silicon Rubber, High Performance Abrasion-resistant Rubber ● Temperature Range: -30℃ to 120℃(According to the working condition) ● Operator: Pneumatic actuator ● Air Supply Pressure: 3-6Bar Product Features:● 100% isolation● Full bore● Only rubber branch pipe in contact with the medium● No leakage, Long service time● Opening tags in the branch pipe● No jamming or clogging, impact resistance● Trouble-free operation● Implement multiple valves united operation, and Remote Control lg...

MVI Control Pinch Valves offer maximum durability with precise control and virtually no maintenance. A heavy-duty, rugged pinch mechanism positions the sleeve, resulting in accurate flow control. Our Control Pinch Valves have no packing to maintain or seats to wear, no fugitive emissions and no need for expensive body alloys. Variable orifice and cone sleeves can be specified to further enhance control performance and match the exact CV level desired. True feedback positioning is accomplished through the direct linkage of the pneumatic positioner to the valve stem shaft, with no splitting of the positioner output. MVI Control Products are available with pneumatic, electropneumatic, or digital positioners to link up to all control systems.lg...
